Mechanical Power Press

AvailabilityIn Stock
CategoryPower Press
Payment MethodsCash, COD, DirectDebit
Rated 0.0/5 based on 0 customer review
5
0
0%
4
0
0%
3
0
0%
2
0
0%
1
0
0%

Mechanical Power Press Details

DESCRIPTION3
TONS
5
TONS
10
TONS
15
TONS
20
TONS
30
TONS
40
TONS
50
TONS
75
TONS
100
TONS
150
TONS
200
TONS
250
TONS
CRANK HAFT DIAMETER3851607076838995114127152158165
STROKE ADJUSTMENT2-196-256-2510-3813-5113-6313-7513-7613-10213-11413-12713-15213-165
HOLE IN RAM192525.432323838384551516363
HOLW IN BED51637680838989102127127152216216
LENGTH & WIDTH OF BED203x152305x178356x203432x229457x305508x356558x381610x406711x457813x508914x610965x6601067x711
DIST. BED TO RAM127153178203229254279350330381419432485
FLY WHEEL DIAMETER3304054355005506607378109101016111811501320
STROKE PER MINUTE85857575606055555040303030
H.P.REQUIRED0.50.511.523457.510152025
WEIGTH APPROX150275400750900110020002200350050006000850011200

FRAME : The frame is made of steel construction and their heavy cross section and rigid design
assure minimum deflection and accurate alignment cast iron legs will be supplied up to 30 ton presses.

CRANK SHAFT : Crank shaft materials are made of special alloy steel to withstand the effective load fitted
in busher with high accuracy.

GEAR : The gears are made of cast steel or fabricated and it teeth are generated by hobbing.

CLUTCH : The cluth is provided of pin / rolling key type also it is rigid and well supported for the mass production clutch can gives continuous stroke.

FLYWHEEL : The flywheel is made of high grade cast iron and is balanced for storng and releasing
adequate energy for the pressing operations.

LUBRICATION : An accurate lubriction system has been proved for lubrications the sliding surfaces and moving parts.

TABLE & RAM : Table and Ram are made of high grade heavy duty cast iron & properly seasoned. they are perfactly aligned to each other to obtain high accuracy & precision press operation.
